KING OF THE HILL

An open-source Battlefield 6 Portal King of the Hill game mode by Enoc Bernal / mindflexor.

This is a Hardpoint-style KOTH mode where both teams fight over one active hill at a time. Hold the hill to score, contest it to deny points, and rotate through the full objective sequence until one team reaches the target score.

Play now:

KOTH Experience Code: 1XPDC

Source Code / Package

GitHub Repository: https://github.com/mindflexor/bf6-koth-mod

This package includes:

TypeScript source code
Portal-ready build workflow
Strings file
Deployment scripts
Optional spatial reference files
Godot spatial project reference
Siege of Cairo KOTH spatial reference
Documentation for rules, object IDs, spawning, and publishing

Mode Overview

King of the Hill - is built around a rotating active objective system.

Teams fight over one active hill at a time. The team holding the active hill earns score every second. If both teams are inside the active hill, the hill becomes contested and no team scores. Empty hills and locked-preview hills do not score.

The mode rotates through five objectives:

A -> B -> C -> D -> E

Core Rules

One active hill at a time
Hills rotate in fixed order: A -> B -> C -> D -> E
Each hill lasts 85 seconds
Next hill appears as a locked preview before it activates
Team 1 alone on the active hill scores +1 per second
Team 2 alone on the active hill scores +1 per second
Enemy presence contests the hill
Contested hills do not score
Empty hills do not score
First team to 250 points wins
Default match time limit: 60000 seconds
Post-match delay: 12 seconds
Victory/defeat imminent warning starts at 225 points

Current Included Map Reference

Siege of Cairo KOTH

Included spatial files:

spatials/MF_Siege_of_CairoKOTH.spatial.json
Godot Project/MF_Siege_of_CairoKOTH.tscn

These files are included as optional spatial references for map authoring and are not imported directly by the TypeScript bundle.

Features

Fully scripted King of the Hill game logic
Five rotating hill objectives
Active objective HUD
Objective status UI
Live score display
Objective timer display
Runtime world icons
Locked next-objective preview
Contested hill state
Victory and defeat imminent banners
Native custom scoreboard columns
Hill time tracking
Kills, deaths, and assists scoreboard support
HQ deploy setup
Runtime spawn routing near active objectives
Spawn safety checks
Enemy-pressure-aware spawn selection
Fallback behavior if configured spawn anchors are missing
Prematch, ready-up, prelive, live, and postmatch flow
Portal deployment workflow through npm scripts

Scoreboard

The custom scoreboard supports:

Score
Kills
Deaths
Assists
Hill Time

Object ID Assignment

Active Hill Area Triggers

501 - Hill A 502 - Hill B 503 - Hill C 504 - Hill D 505 - Hill E

Objective Visibility Sector Layers

200 - Team 1 owned hill sector 300 - Team 2 owned hill sector 400 - Neutral / locked / empty / contested sector

Capture Point Display Objects

201-205 - Team 1 hill capture point display objects 301-305 - Team 2 hill capture point display objects 401-405 - Neutral hill capture point display objects

HQ Spawners

1 - Team 1 HQ 2 - Team 2 HQ

Spawn Presence / Pressure Zones

901 - North West presence zone 902 - North East presence zone 903 - South West presence zone 904 - South East presence zone

Runtime Spawn Anchor Groups

Hill A anchors:

1311-1315
1321-1325
1411-1415
1421-1425

Hill B anchors:

2311-2315
2321-2325
2411-2415
2421-2425

Hill C anchors:

3311-3315
3321-3325
3411-3415
3421-3425

Hill D anchors:

4311-4315
4321-4325
4411-4415
4421-4425

Hill E anchors:

5311-5315
5321-5325
5411-5415
5421-5425

Disabled Legacy HQ IDs

The mode disables legacy HQ IDs:

3-20 8888 8889

Spawn System Notes

The deploy screen keeps Team 1 HQ and Team 2 HQ available.

After deployment, the KOTH runtime queues players to spawn anchors near the active objective. The spawn system evaluates distance, enemy pressure, friendly presence, and safety before choosing a runtime spawn location.

Default spawn tuning:

Ideal objective distance: 60m
Minimum objective distance: 45m
Maximum preferred objective distance: 80m
Hard maximum objective distance: 120m
Enemy safety radius: 25m
Queued anchor enemy safety radius: 40m
Teammate teleport enemy safety radius: 40m

If a configured anchor is missing, the system logs a one-time warning and falls back to the HQ deployment path instead of breaking the match.

Runtime Systems

The mode is organized into live runtime services:

KothHillService Handles hill membership, control state, objective visibility, and rotation.
KothScoreService Handles team score, hill time, win detection, and imminent victory/defeat banners.
KothWorldIconService Handles runtime world icons at hill capture point positions.
KothSpawnService Handles HQ deployment, spawn routing, spawn cluster ownership, queued teleport jobs, and safety checks.
KothScoreboardService Handles native custom scoreboard columns for score, kills, deaths, assists, and hill time.
KothUiService Handles live HUD widgets, objective status, score display, and timers.

The phase runtime handles:

Prematch
Ready-up
Prelive
Live handoff
Postmatch

Map Authoring Notes

To build another map for this mode:

Place hill area triggers using IDs 501-505.
Place capture point display objects using the Team 1, Team 2, and Neutral ID ranges.
Keep sector layers 200, 300, and 400 available for ownership visibility.
Keep HQ spawners 1 and 2 available for deployment.
Place runtime spawn anchor common objects for the configured anchor IDs.
Keep the live KOTH config files synced with your authored object IDs.
Use the included spatial files as a reference for layout and object placement.

Build Requirements

Node.js 24 or newer
Editable Battlefield Portal experience
Portal deployment credentials in .env when deploying

The Portal SDK typing surface is vendored under:

src/vendor/portal-sdk/

This prevents the project from depending on stale public mod type packages.

Build Commands

Install dependencies:

bash npm install
